QD-240/300/350K Granule pre-made bag packing machine
Applicable tea, coffee, frozen products, candy, melon seeds, potato chips,pistachios, peanuts,corn，wheat,nuts, preserved fruit, jelly, frozen rice dumpling, biscuits, preserved fruit, camphor balls, raisins, almonds,chocolate,nuts, grains, pet food, puffed food, small hardware, plastic parts and other granular, sheet, strip, irregular shaped materials.
Scan the QR code to view the product video.
Scan the QR code to view the product video.
Key Features
Using PLC touch screen control, displaying in both Chinese and English, human-machine interface, parameter settina is convenient and fast.- The machine clamp can be synchronously adiusted, and the parameters of the equipment can be saved when producing different products. When changing varieties, they can be retrnieved from the database to complete the process.
- All actions are completed by end face cam. The speed can reach 70 bags/minute during high-speed operation.
- Can intelligently detect whether the bag has been opened and whether the bag has been opened completely. lf it is not suitable for adding materials, do not add materials or heat seal, and do not waste bags and materials.
- Use prefabricated packaging bags, which can be made of special-shaped prefabricated baas, with high sealing quality, beautiful packaging, and improved product grade.
- The machine can be equipped with rotary vacuum pump, coding machine, nitrogen filing device, dust removal device, multi head electronic combination scale,linear scale, turntable scale.
Performance Parameters
| Model | QD-240K | QD-300K | QD-350K |
| Mechanical workstation | 8 workstations | ||
| Workstation process | 1.Put bags 2.reservation 3.open bags 4. adding material 1 5.adding material 2 6.reservation 7.heat sealing 8.shaping+output | ||
| Weighing range | 1500g | 2500g | 5000g |
| Power supply | Electricity, gas | ||
| Bag width | W100-240mm | W180-300mm | W200-350mm |
| Bag length | L150-370mm | L150-450mm | L150-480mm |
| Packing speed | ≤ 60Bags/min | 10-40bags/min | ≤ 30Bags/min |
| Power supply | 380V 50Hz/60Hz 3.0Kw | 380V 50Hz/60Hz 3.8Kw | 380V 50Hz/60Hz 3.8Kw |
| Air pressure displacement | ≥ 0.8Mpa 0.6m³/min | ||
| Overall dimensions | L1860 × W1470 × H1550mm | L2080 × W1720 × H1650mm | L2150 × W2020 × H1700mm |
| Weight | 1500Kg | 1800Kg | 2500Kg |
