QD-180 Pre-made bag packing machine

Suitable for measuring packaging of particles, solids, puffing and other items in the food, pharmaceutical, chemical, and cosmetics industries.

Scan the QR code to view the product video.

Scan the QR code to view the product video.

Key Features

Used for self sealing bags, standing bags, zipper bags, can be evacuated and filled with nitrogen gas. The packaging process is fully automated and does not require manual operation.
Different cutting structures can be selected according to the properties of the filling material, and functions such as printing batch numbers can be configured according to customer requirements.
Adopting touch screen operation, PLC control, automatic compensation for sealing temperature, precise temperature control, and beautiful and elegant sealing.(Can be used as M bag, standing bag, self sealing bag)
Packaging material: Composite film, such as pure aluminum, aluminum plated prefabricated bags, etc.

Performance Parameters

Measuring Scope	20-1000g
Bag length	100 – 290mm
Bag width	130 – 180mm (Equipped with airplane holes and circular holes)
Packing Speed	10-30 bags / min
Dimension	1618 × 1056 × 1334mm (Specifications can be customized)
Weight	500Kg
Total Power	AC220V / 50Hz/60Hz / 3.3Kw
Gas source	≥ 0.6Mpa
