QD-240/300/350F Powder pre-made bag packing machine
Ideal quantitative packaging equipment for powdered(micro powder,ultrafine powder) materials such as pesticides, veterinary drugs,chemical products, additives, flour, milk powder,laundry detergent, salt,solid beverages,white sugar, monosodium glutamate, compound seasonings (such as spicy fresh),natural seasonings (such as Shisanxiang),enzyme preparations, feed, etc.
Scan the QR code to view the product video.
Scan the QR code to view the product video.
Key Features
Easy to operate: PLC control, human-machine interface.- Variable frequency speed regulation: Using a variable frequency adjustment device, the speed can be adjusted freely within the specified range.
- Convenient bag width adiustment: Controlled by a motor, each group of machine clips can be synchronously adjusted with just one button; Equipped with a stirring device to prevent particle material from settling.
- No bag or incomplete bag opening, no additives added.
- No bags or additives, no sealing; Door opening shutdown alarm (optional): no ribbon shutdown alarm.
- Insufficient air pressure, alarm prompt.
- Abnormal sealing temperature, alarm prompt.
- The part in contact with the material is made of 304 stainless steel or food arade plastic, which meets hygiene reguirements.
Performance Parameters
| Model | QD-240F | QD-300F | QD-350F |
| Mechanical workstation | 8 workstations | ||
| Workstation process | 1.Put bags 2.reservation 3.open bags 4. adding material 1 5.adding material 2 6.reservation 7.heat sealing 8. shaping+output | ||
| Weighing range | 1500g | 2500g | 5000g |
| Power supply | Electricity, gas | ||
| Bag width | W100-240mm | W180-300mm | W200-350mm |
| Bag length | L150-370mm | L150-450mm | L150-480mm |
| Packing speed | ≤ 60Bags/min | 10-40bags/min | ≤ 30Bags/min |
| Power supply | 380V 50Hz/60Hz 3.0Kw | 380V 50Hz/60Hz 3.8Kw | 380V 50Hz/60Hz 3.8Kw |
| Air pressure displacement | ≥ 0.8Mpa 0.6m³/min | ||
| Overall dimensions | L1860 × W1470 × H1550mm | L2080 × W1720 × H1650mm | L2150 × W2020 × H1700mm |
| Weight | 1500Kg | 1800Kg | 2500Kg |
