QD-898 High speed automatic packing machine
This series of machines is suitable for high-speed pillow packaging of square, sphercal, circular, cylindrical, button shaped, elliptical, and various shaped candies or fixed shaped blocks. Mainly used for: candy, chocolate, camphor balls, etc.
Scan the QR code to view the product video.
Scan the QR code to view the product video.
Key Features
High sensitivity touch display screen, PLC controller controls the operation of the whole machine, displaying in both Chinese and English, human-machine interface, convenient and fast parameter setting.- Adopting a PlD independent temperature control controller, the temperature control is accurate, the sealing effect is good, and it is also suitable for various packaging materials.
- High sensitivity photoelectric eye color marker tracking, digital input of sealing and cutting position, making the sealing and cutting position more accurate.
- It has a positioning shutdown function, variable frequency/servo control, and the bag length can be set and cut at any time without adiusting the empty path, saving time and effort in one step, without wasting the coating or sticking the knife.
- The machine has a fault self diagnosis function, and the fault display is clear at a glance, helping to troubleshoot in a timely manner.
- This series of machines is suitable for fully automatic sorting and packaging of candies and other regular objects.
- Eauipped with servo motor drive and differential structure, it is convenient and reliable to use, with fast packaging speed and high production efficiency.
- This series of machines can be optionally equipped with a high-speed automatic coding machine to achieve printing of production dates and batches.
- Film types: polyethylene(PE), polypropylene (PP), polyvinyl chloride (PVC), polyester (PET), aluminum plated film, aluminum foil composite film, etc.
Performance Parameters
| Bag size | L48–95 × W20–80mm |
| Product Specifications | L10–50 × W10–30 × H4–25mm |
| Packaging width | 50–120mm |
| Film roll diameter | Max 320mm |
| Outline dimension | L3770 × W670 × H1450mm |
| Power | 220V 380V/3.7Kw |
| Weight | 600Kg |
