QD-5FL Powder filling line
The powder filling production line consists of bottle (can) sorting - intemal blowing of bottles (cans)-bottle (can)sterilization - material conveying - quantitative filling - online weighing and testing→ sealing - printing date - labeling - conveying and other processes.Users can choose the appropnate process flow according to their own materal packaging requirements. This production line is mainly suitable for flling various powders and granular materials, such as milk powder, protein powder, chicken powder, yam powder, Sangi powder, miscellaneous grain powder, solid beverages, veterinary drugs, food additives. etc.
Scan the QR code to view the product video.
Scan the QR code to view the product video.
Key Features
The appearance of the entire set of machines is made of stainless steel material, and all machine structures are designed according to food and medicine hygiene standards.- The entire line equipment is designed according to GMP standards and fully meets the hygiene requirements for shelf food and drugs. Truly achieving full automation of the assembly line, ensuring that personnel do not come into contact with the product throughout the entire production process, and the production process is completely transparent and more reliable.
- The inner walls of the containers in contact with the materials are polished, and the structures that are frequently disassembled and washed are connected using easily detachable parts to ensure more hygienic and convenient handling during shift handover or product changes.
- Can conduct on-site inspections at the factory and design the best production plan on site; Provide free technical support for other aspects of the production line.
Performance Parameters
| Bottle diameter | 35–100mm |
| Bottle height | 40–200mm |
| Suitable lid diameter | 15–100mm |
| Filling range | 50–500g |
| Capacity | ±0.3–1.5g |
| Speed | 30–80Bottle/min |
| Power supply | 3P/380V/50Hz/60Hz |
| Compressed air | 0.6m³/min 0.6–0.8Mpa |
